LG Air Conditioner check motor Air Deflector or Flap falls off, Motor breakdown.

ID: 176397

Description:

Steps:

  1. To reach this point as you see it in photo 1, the previous step is to dismantle the casing, which is covered in Guide 1:
  2. VIDEO: Why am I undertaking this internal parts repair review?
  3. Photo 2, we see the motor causing the problem in close-up.
    4. Step image Step image
  4. Here we see in detail the cause of the breakdown. In photo 2 (inverted) we can easily see its manufacturer's data 28BYJ48 12V
    5. Step image Step image
  5. View of the motor wiring upstream, towards the (PCB) electronic board.
    6. Step image Step image Step image
  6. To remove the motor, we remove the 2 motor screws to check its axis. We can remove the mobile flap or leave it in place, then you just have to fit it when reassembling.
  7. ATTENTION: VERY IMPORTANT! I found replacement motors on Aliexpress, but be careful with the description, there are 2 different measurements between the axis of the support where the screws go, so measure it carefully before deciding on one replacement or another. Another problem that I will deal with in Guide 3: the connector is not the same.
  8. The motor received has a short lead and doesn't have the same type of connector, but it can be adapted.
  9. END of Guide 2, diagnosis of the problem.
    10. Step image Step image
