Smoke Detector Teardown

ID: 23037

Description: For our reverse engineering project, we chose...

Steps:

  1. Use a screwdriver to pry open the plastic enclosure. It might be easier to push the buzzer through the hole, if you need extra leverage.
    2. Step image Step image
  2. The buzzer is unhooked from the PCB board, by hands.
    3. Step image
  3. This is the circuit for the smoke detector. It is powered by a 9V battery. The 3 metal leafs are contacts for the buzzer and the bigger leaf is for the test button.
    4. Step image Step image
  4. The metal cap is removed to reveal a, MC145017, driver chip and americium sensor. Do not remove americium from the sensor!
    5. Step image
